Waipiata Details

Property	Value
Rupture Count	510
Ruptures Above Sect Min Mag	509
Ruptures w/ Nonzero Rates	10
Magnitude Range	[6.89, 8.00]
Length Range	[23, 266] km
Total Rate	2.7686587E-5 /yr
Multi-Fault Rate	2.7686587E-5 /yr (100.00%)
Directly-Connected Faults	6
All Co-Rupturing Faults	20

Table Of Contents

Magnitude-Frequency Distribution
Along-Strike Values
- Moment-Rates and b-Values
Connectivity
- Nearby Sections

Magnitude-Frequency Distribution

Incremental	Cumulative

Along-Strike Values

Moment-Rates and b-Values

Connectivity

Nearby Sections

Fault Section	Fault Section
Horse Flat, 0.04 km away	Logan Burn, 6.3 km away
Billys Ridge, 0.15 km away	Gimmerburn, 7.59 km away
Murphys Creek, 0.26 km away	Waihemo, 7.68 km away
Hyde North, 0.37 km away	Nichols Rock, 8.69 km away
Dunback Hill, 0.64 km away	Cross Eden, 10.38 km away
Ranfurly, 2.79 km away	Long Valley, 12.3 km away
Pylap, 3.22 km away	Sliver Stream - Merton, 16.88 km away
Flat Stream - Glenpark, 6.13 km away	Hawkdun, 17.13 km away

Horse Flat, 0.04 km away

(back to table)

	Solution Diagnostics: SW52ZXJzaW9uU29sdXRpb246MTEzMDUw
Connected?	true
Directly Connected?	false
Co-rupture Count	11
Co-rupture Rate	0.0

Billys Ridge, 0.15 km away

(back to table)

	Solution Diagnostics: SW52ZXJzaW9uU29sdXRpb246MTEzMDUw
Connected?	true
Directly Connected?	true
Min Co-Rupture Dist	0.15 km
Co-rupture Count	134
Co-rupture Rate	2.381669E-6

Murphys Creek, 0.26 km away

(back to table)

	Solution Diagnostics: SW52ZXJzaW9uU29sdXRpb246MTEzMDUw
Connected?	true
Directly Connected?	true
Min Co-Rupture Dist	0.29 km
Min Rate-Weighted Dist	0.29 km
Co-rupture Count	50
Co-rupture Rate	7.128597E-7

Hyde North, 0.37 km away

(back to table)

	Solution Diagnostics: SW52ZXJzaW9uU29sdXRpb246MTEzMDUw
Connected?	true
Directly Connected?	true
Min Co-Rupture Dist	0.37 km
Min Rate-Weighted Dist	0.37 km
Co-rupture Count	172
Co-rupture Rate	2.5113206E-5

Dunback Hill, 0.64 km away

(back to table)

	Solution Diagnostics: SW52ZXJzaW9uU29sdXRpb246MTEzMDUw
Connected?	true
Directly Connected?	true
Min Co-Rupture Dist	0.64 km
Min Rate-Weighted Dist	1.2 km
Co-rupture Count	247
Co-rupture Rate	9.345966E-6

Ranfurly, 2.79 km away

(back to table)

	Solution Diagnostics: SW52ZXJzaW9uU29sdXRpb246MTEzMDUw
Connected?	true
Directly Connected?	true
Min Co-Rupture Dist	2.79 km
Min Rate-Weighted Dist	2.79 km
Co-rupture Count	226
Co-rupture Rate	1.188496E-5

Pylap, 3.22 km away

(back to table)

	Solution Diagnostics: SW52ZXJzaW9uU29sdXRpb246MTEzMDUw
Connected?	true
Directly Connected?	true
Min Co-Rupture Dist	3.22 km
Co-rupture Count	48
Co-rupture Rate	0.0

Flat Stream - Glenpark, 6.13 km away

(back to table)

	Solution Diagnostics: SW52ZXJzaW9uU29sdXRpb246MTEzMDUw
Connected?	true
Directly Connected?	false
Co-rupture Count	18
Co-rupture Rate	0.0

Logan Burn, 6.3 km away

(back to table)

	Solution Diagnostics: SW52ZXJzaW9uU29sdXRpb246MTEzMDUw
Connected?	true
Directly Connected?	false
Co-rupture Count	194
Co-rupture Rate	2.381669E-6

Gimmerburn, 7.59 km away

(back to table)

	Solution Diagnostics: SW52ZXJzaW9uU29sdXRpb246MTEzMDUw
Connected?	false
Directly Connected?	false
Co-rupture Count	0
Co-rupture Rate	N/A

Waihemo, 7.68 km away

(back to table)

	Solution Diagnostics: SW52ZXJzaW9uU29sdXRpb246MTEzMDUw
Connected?	false
Directly Connected?	false
Co-rupture Count	0
Co-rupture Rate	N/A

Nichols Rock, 8.69 km away

(back to table)

	Solution Diagnostics: SW52ZXJzaW9uU29sdXRpb246MTEzMDUw
Connected?	true
Directly Connected?	false
Co-rupture Count	256
Co-rupture Rate	5.391296E-6

Cross Eden, 10.38 km away

(back to table)

	Solution Diagnostics: SW52ZXJzaW9uU29sdXRpb246MTEzMDUw
Connected?	false
Directly Connected?	false
Co-rupture Count	0
Co-rupture Rate	N/A

Long Valley, 12.3 km away

(back to table)

	Solution Diagnostics: SW52ZXJzaW9uU29sdXRpb246MTEzMDUw
Connected?	false
Directly Connected?	false
Co-rupture Count	0
Co-rupture Rate	N/A

Sliver Stream - Merton, 16.88 km away

(back to table)

	Solution Diagnostics: SW52ZXJzaW9uU29sdXRpb246MTEzMDUw
Connected?	false
Directly Connected?	false
Co-rupture Count	0
Co-rupture Rate	N/A

Hawkdun, 17.13 km away

(back to table)

	Solution Diagnostics: SW52ZXJzaW9uU29sdXRpb246MTEzMDUw
Connected?	false
Directly Connected?	false
Co-rupture Count	0
Co-rupture Rate	N/A
