Whakatane: South Details

PropertyValue
Rupture Count8,955
Ruptures Above Sect Min Mag8,953
Ruptures w/ Nonzero Rates77
Magnitude Range[7.04, 8.59]
Length Range[26, 1,068] km
Total Rate3.7620368E-4 /yr
Multi-Fault Rate3.7620368E-4 /yr (100.00%)
Directly-Connected Faults5
All Co-Rupturing Faults97

Table Of Contents

Magnitude-Frequency Distribution

(top)

IncrementalCumulative
Incremental PlotCumulative Plot

Along-Strike Values

(top)

Along-strike plot

Moment-Rates and b-Values

(top)

Along-strike plot

Connectivity

(top)

MapMap

Nearby Sections

(top)

Fault Section
Waimana: South, 0 km away
Whakatane: North, 0 km away
Mohaka: North, 0 km away
Waiohau: South, 4.67 km away
Waimana: North, 5.63 km away
Waiotahi: South, 5.93 km away
Waiotahi: North, 10.09 km away
Waiohau: North, 11.09 km away
Ruahine: North, 11.52 km away
Te Whaiti South, 11.9 km away
Patoka - Rangiora, 12.36 km away
Wheao: South, 14.52 km away

Waimana: South, 0 km away

(back to table)

Solution Diagnostics: SW52ZXJzaW9uU29sdXRpb246MTc2NTcuMFBuUjdE
Connected?true
Directly Connected?true
Co-rupture Count693
Co-rupture Rate0.0

Whakatane: North, 0 km away

(back to table)

Solution Diagnostics: SW52ZXJzaW9uU29sdXRpb246MTc2NTcuMFBuUjdE
Connected?true
Directly Connected?true
Co-rupture Count3,688
Co-rupture Rate3.5479438E-4

Mohaka: North, 0 km away

(back to table)

Solution Diagnostics: SW52ZXJzaW9uU29sdXRpb246MTc2NTcuMFBuUjdE
Connected?true
Directly Connected?true
Co-rupture Count7,813
Co-rupture Rate2.3187128E-4

Waiohau: South, 4.67 km away

(back to table)

Solution Diagnostics: SW52ZXJzaW9uU29sdXRpb246MTc2NTcuMFBuUjdE
Connected?true
Directly Connected?true
Co-rupture Count1,858
Co-rupture Rate0.0

Waimana: North, 5.63 km away

(back to table)

Solution Diagnostics: SW52ZXJzaW9uU29sdXRpb246MTc2NTcuMFBuUjdE
Connected?true
Directly Connected?false
Co-rupture Count19
Co-rupture Rate0.0

Waiotahi: South, 5.93 km away

(back to table)

Solution Diagnostics: SW52ZXJzaW9uU29sdXRpb246MTc2NTcuMFBuUjdE
Connected?true
Directly Connected?false
Co-rupture Count40
Co-rupture Rate9.0541165E-5

Waiotahi: North, 10.09 km away

(back to table)

Solution Diagnostics: SW52ZXJzaW9uU29sdXRpb246MTc2NTcuMFBuUjdE
Connected?true
Directly Connected?false
Co-rupture Count21
Co-rupture Rate9.0541165E-5

Waiohau: North, 11.09 km away

(back to table)

Solution Diagnostics: SW52ZXJzaW9uU29sdXRpb246MTc2NTcuMFBuUjdE
Connected?false
Directly Connected?false
Co-rupture Count0
Co-rupture RateN/A

Ruahine: North, 11.52 km away

(back to table)

Solution Diagnostics: SW52ZXJzaW9uU29sdXRpb246MTc2NTcuMFBuUjdE
Connected?true
Directly Connected?false
Co-rupture Count1,106
Co-rupture Rate0.0

Te Whaiti South, 11.9 km away

(back to table)

Solution Diagnostics: SW52ZXJzaW9uU29sdXRpb246MTc2NTcuMFBuUjdE
Connected?true
Directly Connected?true
Co-rupture Count186
Co-rupture Rate4.1125877E-5

Patoka - Rangiora, 12.36 km away

(back to table)

Solution Diagnostics: SW52ZXJzaW9uU29sdXRpb246MTc2NTcuMFBuUjdE
Connected?true
Directly Connected?false
Co-rupture Count512
Co-rupture Rate3.7408863E-5

Wheao: South, 14.52 km away

(back to table)

Solution Diagnostics: SW52ZXJzaW9uU29sdXRpb246MTc2NTcuMFBuUjdE
Connected?false
Directly Connected?false
Co-rupture Count0
Co-rupture RateN/A
