Kaiwara North Details

PropertyValue
Rupture Count6,647
Ruptures Above Sect Min Mag6,647
Ruptures w/ Nonzero Rates21
Magnitude Range[7.03, 8.29]
Length Range[25, 560] km
Total Rate1.2870604E-4 /yr
Multi-Fault Rate1.2870604E-4 /yr (100.00%)
Directly-Connected Faults6
All Co-Rupturing Faults91

Table Of Contents

Magnitude-Frequency Distribution

(top)

IncrementalCumulative
Incremental PlotCumulative Plot

Along-Strike Values

(top)

Along-strike plot

Moment-Rates and b-Values

(top)

Along-strike plot

Connectivity

(top)

MapMap

Nearby Sections

(top)

Fault SectionFault Section
Lowry, 0.15 km awayHanmer, 5.4 km away
The Humps, 0.22 km awayHope: Conway, 6.51 km away
Leonard Mound, 0.3 km awayHawkswood, 9.21 km away
Mt Culverden, 0.53 km awayOmihiLwrHuru, 10.71 km away
Leader: South, 0.57 km awayLeader: North, 10.78 km away
Leader: Central, 2.03 km awayKaiwara South, 11.67 km away
Hundalee, 3.47 km awayHope: Hamner SE, 12.43 km away
Alexander, 5.18 km awayStoneJug, 13.46 km away

Lowry, 0.15 km away

(back to table)

Solution Diagnostics: SW52ZXJzaW9uU29sdXRpb246MTc4MzIuMFJtM2Rr
Connected?true
Directly Connected?true
Co-rupture Count2,422
Co-rupture Rate0.0

The Humps, 0.22 km away

(back to table)

Solution Diagnostics: SW52ZXJzaW9uU29sdXRpb246MTc4MzIuMFJtM2Rr
Connected?false
Directly Connected?false
Co-rupture Count0
Co-rupture RateN/A

Leonard Mound, 0.3 km away

(back to table)

Solution Diagnostics: SW52ZXJzaW9uU29sdXRpb246MTc4MzIuMFJtM2Rr
Connected?true
Directly Connected?true
Co-rupture Count424
Co-rupture Rate1.2870604E-4

Mt Culverden, 0.53 km away

(back to table)

Solution Diagnostics: SW52ZXJzaW9uU29sdXRpb246MTc4MzIuMFJtM2Rr
Connected?true
Directly Connected?true
Co-rupture Count2,537
Co-rupture Rate0.0

Leader: South, 0.57 km away

(back to table)

Solution Diagnostics: SW52ZXJzaW9uU29sdXRpb246MTc4MzIuMFJtM2Rr
Connected?false
Directly Connected?false
Co-rupture Count0
Co-rupture RateN/A

Leader: Central, 2.03 km away

(back to table)

Solution Diagnostics: SW52ZXJzaW9uU29sdXRpb246MTc4MzIuMFJtM2Rr
Connected?true
Directly Connected?true
Co-rupture Count6,159
Co-rupture Rate2.5343505E-5

Hundalee, 3.47 km away

(back to table)

Solution Diagnostics: SW52ZXJzaW9uU29sdXRpb246MTc4MzIuMFJtM2Rr
Connected?true
Directly Connected?true
Co-rupture Count174
Co-rupture Rate0.0

Alexander, 5.18 km away

(back to table)

Solution Diagnostics: SW52ZXJzaW9uU29sdXRpb246MTc4MzIuMFJtM2Rr
Connected?true
Directly Connected?true
Co-rupture Count1,296
Co-rupture Rate0.0

Hanmer, 5.4 km away

(back to table)

Solution Diagnostics: SW52ZXJzaW9uU29sdXRpb246MTc4MzIuMFJtM2Rr
Connected?false
Directly Connected?false
Co-rupture Count0
Co-rupture RateN/A

Hope: Conway, 6.51 km away

(back to table)

Solution Diagnostics: SW52ZXJzaW9uU29sdXRpb246MTc4MzIuMFJtM2Rr
Connected?true
Directly Connected?false
Co-rupture Count4,692
Co-rupture Rate2.407978E-5

Hawkswood, 9.21 km away

(back to table)

Solution Diagnostics: SW52ZXJzaW9uU29sdXRpb246MTc4MzIuMFJtM2Rr
Connected?false
Directly Connected?false
Co-rupture Count0
Co-rupture RateN/A

OmihiLwrHuru, 10.71 km away

(back to table)

Solution Diagnostics: SW52ZXJzaW9uU29sdXRpb246MTc4MzIuMFJtM2Rr
Connected?true
Directly Connected?false
Co-rupture Count97
Co-rupture Rate0.0

Leader: North, 10.78 km away

(back to table)

Solution Diagnostics: SW52ZXJzaW9uU29sdXRpb246MTc4MzIuMFJtM2Rr
Connected?true
Directly Connected?false
Co-rupture Count1,220
Co-rupture Rate1.263725E-6

Kaiwara South, 11.67 km away

(back to table)

Solution Diagnostics: SW52ZXJzaW9uU29sdXRpb246MTc4MzIuMFJtM2Rr
Connected?true
Directly Connected?false
Co-rupture Count632
Co-rupture Rate0.0

Hope: Hamner SE, 12.43 km away

(back to table)

Solution Diagnostics: SW52ZXJzaW9uU29sdXRpb246MTc4MzIuMFJtM2Rr
Connected?false
Directly Connected?false
Co-rupture Count0
Co-rupture RateN/A

StoneJug, 13.46 km away

(back to table)

Solution Diagnostics: SW52ZXJzaW9uU29sdXRpb246MTc4MzIuMFJtM2Rr
Connected?false
Directly Connected?false
Co-rupture Count0
Co-rupture RateN/A
