Cross Eden Details

PropertyValue
Rupture Count1,007
Ruptures Above Sect Min Mag1,006
Ruptures w/ Nonzero Rates14
Magnitude Range[6.75, 8.13]
Length Range[19, 353] km
Total Rate1.5850224E-4 /yr
Multi-Fault Rate1.5850224E-4 /yr (100.00%)
Directly-Connected Faults5
All Co-Rupturing Faults38

Table Of Contents

Magnitude-Frequency Distribution

(top)

IncrementalCumulative
Incremental PlotCumulative Plot

Along-Strike Values

(top)

Along-strike plot

Moment-Rates and b-Values

(top)

Along-strike plot

Connectivity

(top)

MapMap

Nearby Sections

(top)

Fault Section
Hyde North, 0.16 km away
Waihemo, 1.14 km away
Gimmerburn, 2.3 km away
Hawkdun, 3.2 km away
Ranfurly, 4.41 km away
Horse Flat, 7.35 km away
Garibaldi, 7.5 km away
Waipiata, 10.37 km away
Billys Ridge, 12.78 km away

Hyde North, 0.16 km away

(back to table)

Solution Diagnostics: SW52ZXJzaW9uU29sdXRpb246MjExNDYuMHhrWlpv
Connected?true
Directly Connected?true
Co-rupture Count742
Co-rupture Rate2.6803491E-5

Waihemo, 1.14 km away

(back to table)

Solution Diagnostics: SW52ZXJzaW9uU29sdXRpb246MjExNDYuMHhrWlpv
Connected?true
Directly Connected?false
Co-rupture Count35
Co-rupture Rate1.5895499E-5

Gimmerburn, 2.3 km away

(back to table)

Solution Diagnostics: SW52ZXJzaW9uU29sdXRpb246MjExNDYuMHhrWlpv
Connected?true
Directly Connected?true
Co-rupture Count172
Co-rupture Rate0.0

Hawkdun, 3.2 km away

(back to table)

Solution Diagnostics: SW52ZXJzaW9uU29sdXRpb246MjExNDYuMHhrWlpv
Connected?true
Directly Connected?true
Co-rupture Count830
Co-rupture Rate3.8622497E-5

Ranfurly, 4.41 km away

(back to table)

Solution Diagnostics: SW52ZXJzaW9uU29sdXRpb246MjExNDYuMHhrWlpv
Connected?true
Directly Connected?true
Co-rupture Count35
Co-rupture Rate0.0

Horse Flat, 7.35 km away

(back to table)

Solution Diagnostics: SW52ZXJzaW9uU29sdXRpb246MjExNDYuMHhrWlpv
Connected?true
Directly Connected?false
Co-rupture Count34
Co-rupture Rate0.0

Garibaldi, 7.5 km away

(back to table)

Solution Diagnostics: SW52ZXJzaW9uU29sdXRpb246MjExNDYuMHhrWlpv
Connected?false
Directly Connected?false
Co-rupture Count0
Co-rupture RateN/A

Waipiata, 10.37 km away

(back to table)

Solution Diagnostics: SW52ZXJzaW9uU29sdXRpb246MjExNDYuMHhrWlpv
Connected?true
Directly Connected?false
Co-rupture Count2
Co-rupture Rate0.0

Billys Ridge, 12.78 km away

(back to table)

Solution Diagnostics: SW52ZXJzaW9uU29sdXRpb246MjExNDYuMHhrWlpv
Connected?true
Directly Connected?true
Co-rupture Count42
Co-rupture Rate1.3169875E-4
