F16 - Central Details

PropertyValue
Rupture Count27,464
Ruptures Above Sect Min Mag27,462
Ruptures w/ Nonzero Rates110
Magnitude Range[7.06, 8.43]
Length Range[26, 701] km
Total Rate0.0024600022 /yr
Multi-Fault Rate9.787328E-4 /yr (39.79%)
Directly-Connected Faults11
All Co-Rupturing Faults64

Table Of Contents

Magnitude-Frequency Distribution

(top)

IncrementalCumulative
Incremental PlotCumulative Plot

Along-Strike Values

(top)

Along-strike plot

Moment-Rates and b-Values

(top)

Along-strike plot

Connectivity

(top)

MapMap

Nearby Sections

(top)

Fault Section
BKSmt-North, 0.11 km away
BKSmt-West, 0.19 km away
Aorangi Ridge, 0.8 km away
Bennett Knoll, 1.07 km away
F16 - South, 1.46 km away
Akitio Ridge, 2.28 km away
F17 - Central, 3.82 km away
F14 - North, 4.34 km away
F17 - South, 5.88 km away
Aorangi Trough, 5.98 km away
Akitio Trough West, 8.18 km away
F16 - North, 10.71 km away
Porangahau Northeast, 14.86 km away

BKSmt-North, 0.11 km away

(back to table)

Solution Diagnostics: SW52ZXJzaW9uU29sdXRpb246MjEzMDAuMGhwY1B2
Connected?true
Directly Connected?true
Co-rupture Count7,843
Co-rupture Rate2.6100545E-4

BKSmt-West, 0.19 km away

(back to table)

Solution Diagnostics: SW52ZXJzaW9uU29sdXRpb246MjEzMDAuMGhwY1B2
Connected?true
Directly Connected?true
Co-rupture Count3,044
Co-rupture Rate1.081235E-4

Aorangi Ridge, 0.8 km away

(back to table)

Solution Diagnostics: SW52ZXJzaW9uU29sdXRpb246MjEzMDAuMGhwY1B2
Connected?true
Directly Connected?true
Co-rupture Count12,501
Co-rupture Rate4.6784288E-4

Bennett Knoll, 1.07 km away

(back to table)

Solution Diagnostics: SW52ZXJzaW9uU29sdXRpb246MjEzMDAuMGhwY1B2
Connected?true
Directly Connected?true
Co-rupture Count238
Co-rupture Rate1.7190765E-5

F16 - South, 1.46 km away

(back to table)

Solution Diagnostics: SW52ZXJzaW9uU29sdXRpb246MjEzMDAuMGhwY1B2
Connected?true
Directly Connected?true
Co-rupture Count5,019
Co-rupture Rate1.5563711E-4

Akitio Ridge, 2.28 km away

(back to table)

Solution Diagnostics: SW52ZXJzaW9uU29sdXRpb246MjEzMDAuMGhwY1B2
Connected?true
Directly Connected?true
Co-rupture Count20,476
Co-rupture Rate5.037629E-6

F17 - Central, 3.82 km away

(back to table)

Solution Diagnostics: SW52ZXJzaW9uU29sdXRpb246MjEzMDAuMGhwY1B2
Connected?true
Directly Connected?true
Co-rupture Count4,061
Co-rupture Rate2.0260566E-4

F14 - North, 4.34 km away

(back to table)

Solution Diagnostics: SW52ZXJzaW9uU29sdXRpb246MjEzMDAuMGhwY1B2
Connected?true
Directly Connected?true
Co-rupture Count8,943
Co-rupture Rate1.0149025E-4

F17 - South, 5.88 km away

(back to table)

Solution Diagnostics: SW52ZXJzaW9uU29sdXRpb246MjEzMDAuMGhwY1B2
Connected?true
Directly Connected?true
Co-rupture Count7,111
Co-rupture Rate9.615267E-5

Aorangi Trough, 5.98 km away

(back to table)

Solution Diagnostics: SW52ZXJzaW9uU29sdXRpb246MjEzMDAuMGhwY1B2
Connected?true
Directly Connected?true
Co-rupture Count7,360
Co-rupture Rate3.4281853E-5

Akitio Trough West, 8.18 km away

(back to table)

Solution Diagnostics: SW52ZXJzaW9uU29sdXRpb246MjEzMDAuMGhwY1B2
Connected?true
Directly Connected?true
Co-rupture Count1,747
Co-rupture Rate1.7702956E-5

F16 - North, 10.71 km away

(back to table)

Solution Diagnostics: SW52ZXJzaW9uU29sdXRpb246MjEzMDAuMGhwY1B2
Connected?true
Directly Connected?false
Co-rupture Count1,434
Co-rupture Rate2.4114421E-4

Porangahau Northeast, 14.86 km away

(back to table)

Solution Diagnostics: SW52ZXJzaW9uU29sdXRpb246MjEzMDAuMGhwY1B2
Connected?false
Directly Connected?false
Co-rupture Count0
Co-rupture RateN/A
