West Wakatipu Details

PropertyValue
Rupture Count2,292
Ruptures Above Sect Min Mag2,290
Ruptures w/ Nonzero Rates60
Magnitude Range[7.05, 8.51]
Length Range[25, 946] km
Total Rate2.7962449E-6 /yr
Multi-Fault Rate2.5082502E-6 /yr (89.70%)
Directly-Connected Faults3
All Co-Rupturing Faults89

Table Of Contents

Magnitude-Frequency Distribution

(top)

IncrementalCumulative
Incremental PlotCumulative Plot

Along-Strike Values

(top)

Along-strike plot

Moment-Rates and b-Values

(top)

Along-strike plot

Connectivity

(top)

MapMap

Nearby Sections

(top)

Fault Section
Moonlight North, 0.14 km away
Moonlight South, 1.86 km away
Livingstone, 7.08 km away
Nevis, 7.52 km away
NW Cardrona South, 12.07 km away
Darran, 12.9 km away
Hollyford, 13.88 km away
Te Anau, 17.12 km away

Moonlight North, 0.14 km away

(back to table)

Solution Diagnostics: SW52ZXJzaW9uU29sdXRpb246MjM2OTguMFZRWEw3
Connected?true
Directly Connected?true
Co-rupture Count1,975
Co-rupture Rate3.6119908E-7

Moonlight South, 1.86 km away

(back to table)

Solution Diagnostics: SW52ZXJzaW9uU29sdXRpb246MjM2OTguMFZRWEw3
Connected?false
Directly Connected?false
Co-rupture Count0
Co-rupture RateN/A

Livingstone, 7.08 km away

(back to table)

Solution Diagnostics: SW52ZXJzaW9uU29sdXRpb246MjM2OTguMFZRWEw3
Connected?false
Directly Connected?false
Co-rupture Count0
Co-rupture RateN/A

Nevis, 7.52 km away

(back to table)

Solution Diagnostics: SW52ZXJzaW9uU29sdXRpb246MjM2OTguMFZRWEw3
Connected?true
Directly Connected?true
Co-rupture Count184
Co-rupture Rate8.430163E-9

NW Cardrona South, 12.07 km away

(back to table)

Solution Diagnostics: SW52ZXJzaW9uU29sdXRpb246MjM2OTguMFZRWEw3
Connected?true
Directly Connected?false
Co-rupture Count4
Co-rupture Rate0.0

Darran, 12.9 km away

(back to table)

Solution Diagnostics: SW52ZXJzaW9uU29sdXRpb246MjM2OTguMFZRWEw3
Connected?true
Directly Connected?true
Co-rupture Count309
Co-rupture Rate2.147051E-6

Hollyford, 13.88 km away

(back to table)

Solution Diagnostics: SW52ZXJzaW9uU29sdXRpb246MjM2OTguMFZRWEw3
Connected?false
Directly Connected?false
Co-rupture Count0
Co-rupture RateN/A

Te Anau, 17.12 km away

(back to table)

Solution Diagnostics: SW52ZXJzaW9uU29sdXRpb246MjM2OTguMFZRWEw3
Connected?false
Directly Connected?false
Co-rupture Count0
Co-rupture RateN/A
